Making skateboard for robot
ロボットが乗るメカナムホイール搭載のスケートボードを制作中。
MTRL京都のレーザーカッターを使用。新しい機械になって切削面積が広くなったのでありがたい。
5㎜のアクリルにしたけど、重量に耐えれるかどうか。
8月24日
Assembly Smith (2) Mecanum Wheel
This is the second installment of a
series that introduces the process of
building robots in British Englsih.
The robot car I made earlier is too
big, so I decided to make a smaller
one for Maker Fair Tokyo 2020.
I am planning to make it with a smoke
gray acrylic in consideration of steam
punk and with a shape like a
skateboard.
It may be more like a scooter than a
skateboard because it has a handle.
LED rings are used around the wheels.
Last time it was heavy and I had a lot
of hard work around the battery, so
this time I'd like to to run it on a
mobile battery.
9th movie "Legs"- The structure of original
humanoid robot
At
last, the explanation of the hardware
from the head to the legs is over.
Next time, I will introduce
peripherals such as batteries and
power supplies,
software to make movement, production
of parts such as cutting of frames and
anodic oxide coating.
8月17日
スケボー
Skateboards have been selected as
official events for the Tokyo Olympics
2020.
東京オリンピックでも正式種目に選ばれたということで、パンダのロボットにスケボーをさせてみました。
手で押して初速をつけて坂を下らせ、自分が映り込まないようにさっと退避するという原始的な方法で撮影しています。
けっこうな傾斜がないと途中で止まってしまうということが分かりました。
8月11日
Assembly Smith (1) - Tomato's head
I'm trying to introduce the process of
crafting and building for a while.
I take videos and photos when making
or repairing new ones and add
explanations.
There are lots of things that you will
not notice unless I explain it, and
questions that are often asked at the
time of exhibition, so it seems that I
can make as many videos as I want.
It's not fun just to explain it, so I
chose English speaker. How about that?
The dad's trilogy is finally over!
Can a father who was imprisoned for
making illegal documents return home?
A mysterious lady from Osaka also
debuted for the first time!
It is a story of family love that
cannot be told without tears!
I haven't been able to use Chroma Key
well yet, but I feel like I have come
to understand it.
